Class 12 Physics Moving Charges And Magnetism Complete Revision

Moving Charges and Magnetism bridges electrostatics and electrodynamics by examining how electric currents generate magnetic fields. Understanding these interactions is vital for mastering core electromagnetic concepts and modern electrical instrumentation.

This chapter connects current, magnetic fields, force, circular motion, electromagnetic instruments, and atomic magnetism. The most important analytical tools are the right-hand thumb rule, Biot–Savart’s law, Ampere’s circuital law, and the Lorentz force equation. It provides an efficient, formula-driven reference designed for high-scoring board exam preparation.

Oersted’s Experiment and Magnetic Effect of Current

A compass needle normally aligns with Earth’s magnetic field. When placed near a current-carrying wire, it deflects. Reversing the current reverses the deflection direction. This proves that electric currents produce magnetic fields.

Iron filings sprinkled around a straight current-carrying wire settle into concentric circles representing magnetic field lines centred on the wire. This confirmed that magnetic effects can arise from electric currents, not just permanent magnets.

A current-carrying conductor remains electrically neutral overall. A stationary charge near it feels zero magnetic force, but a moving charge experiences deflection. Hence, moving charges produce and interact with magnetic fields.

Magnetic Field Due To A Moving Charge

For a charge q moving with velocity v, the magnetic field B at distance r is:

B = (μ₀ / 4π) × (q × v × sin θ) / r²

where θ is the angle between velocity vector v and position vector r, with: μ₀ / 4π = 10⁻⁷ T·m/A, and μ₀ = 4π × 10⁻⁷ T·m/A.

Vector Form: B = (μ₀ / 4π) × [q( v × r̂ ) / r²] = (μ₀ / 4π) × [q( v × r ) / r³]

Direction rules:

• Positive charge: Along (v × r)

• Negative charge: Opposite to (v × r)

The SI unit of magnetic field is the tesla (T): 1 gauss (G) = 10⁻⁴ tesla (T).

Biot–Savart’s Law

For an infinitesimal current element I dl, the magnetic field dB is:

dB = (μ₀ / 4π) × (I × dl × sin θ) / r²

Vector Form: dB = (μ₀ / 4π) × [I (dl × r̂) / r²]

Here, dl is directed along the conventional current flow.

Right-Hand Thumb Rule:

• Point the right thumb along the current direction.

• The curled fingers indicate the direction of magnetic field lines. (Memory Tip: For circular loops, anticlockwise current indicates an outward magnetic field/North pole; clockwise current indicates an inward magnetic field/South pole).

Magnetic Field Due To A Straight Wire

For a straight finite wire carrying current I at perpendicular distance d:

B = (μ₀ I / 4π d) × (sin θ₁ + sin θ₂)

Special Cases:

• Semi-infinite wire: B = μ₀ I / (4π d)

• Infinite straight wire: B = μ₀ I / (2π d)

• Semi-infinite wire with one arbitrary end: B = (μ₀ I / 4π d) × (1 + sin θ)

At any point lying along the axis of the wire itself, dl is parallel to r (dl × r = 0), so B = 0.

Circular Arc And Loop

For a circular arc of radius r subtending an angle θ (in radians) at the centre:

B = (μ₀ I θ) / (4π r)

Special Cases:

• Semicircular wire: B = μ₀ I / (4r)

• Complete single circular loop: B = μ₀ I / (2r)

• Coil with n turns: B = μ₀ n I / (2r)

Magnetic Field on the Axis of a Circular Loop: At axial distance x from a loop of radius r having n turns:

B = [μ₀ n I r²] / [2(r² + x²)³/²]

Perpendicular field components cancel by symmetry, while axial components add up.

Ampere’s Circuital Law And Applications

Ampere’s circuital law states that the line integral of the magnetic field B around any closed loop equals μ₀ times the net enclosed current:

∮ B · dl = μ₀ I_enclosed

Standard Results:

• Infinite straight conductor: B = μ₀ I / (2π r)

• Hollow cylindrical pipe (inside, r < R): B = 0

• Hollow cylindrical pipe (outside, r > R): B = μ₀ I / (2π r)

• Solid cylinder (inside, r < R): B = (μ₀ I r) / (2π R²)

• Solid cylinder (outside, r > R): B = μ₀ I / (2π r)

• Infinite current-carrying sheet: B = μ₀ λ / 2 (where λ is linear current density)

• Ideal long solenoid: Inside, B = μ₀ n I; Outside, B = 0

• Toroid: B = (μ₀ N I) / (2π r) = μ₀ n I

(Memory Tip: Inside a solid conductor, B grows linearly with r; outside, it falls off as 1/r).

Magnetic Force And Lorentz Force

The magnetic force acting on a charge q moving in a field B is:

F_B = q ( v × B ) Magnitude: F_B = q v B sin θ

Key characteristics:

• F_B = 0 when the charge is stationary (v = 0) or moving parallel/antiparallel to the field (θ = 0° or 180°).

• F_B is maximum when velocity is perpendicular to the field (θ = 90°).

• Because F_B is always perpendicular to velocity v, it does no work: F_B · v = 0 => Work W = 0 => ΔK = 0.

• A magnetic field changes the direction of motion, never the speed or kinetic energy.

Total Lorentz Force (combined electric and magnetic fields): F = q E + q ( v × B )

Circular And Helical Motion

When a charged particle enters perpendicular to a uniform magnetic field (θ = 90°), magnetic force supplies the centripetal force:

q v B = m v² / r

• Radius of path: r = (m v) / (q B) = p / (q B) = √(2 m K) / (q B)

• Time period: T = 2π m / (q B)

• Frequency: f = (q B) / (2π m)

Note that the time period T and frequency f are completely independent of speed and radius.

Helical Motion (entry at angle θ):

• Parallel velocity: v_parallel = v cos θ

• Perpendicular velocity: v_perp = v sin θ

• Helix radius: r = (m v sin θ) / (q B)

• Pitch of helix: Pitch = v_parallel × T = (2π m v cos θ) / (q B)

Velocity Selector And Mass Spectrometer

In crossed (mutually perpendicular) electric and magnetic fields, a charged particle moves undeflected when electric force balances magnetic force:

q E = q v B => v = E / B

A mass spectrometer uses this velocity filter to separate ions based on specific charge (q/m):

r = (m v) / (q B) => q / m = v / (B r)

Cyclotron

A cyclotron accelerates positive ions to high kinetic energies using alternating electric fields across two dees in a perpendicular magnetic field.

• Cyclotron frequency: f = (q B) / (2π m)

• Resonance condition: The frequency of the applied radio-frequency oscillator must match the cyclotron frequency.

• Maximum kinetic energy: K_max = (q² B² R²) / (2m), where R is the exit radius of the dees.

Force On Current-Carrying Conductors

For an infinitesimal current element in a magnetic field: dF = I ( dl × B )

For a straight conductor of length L: F = I ( L × B ). Magnitude: F = I L B sin θ

• In a uniform magnetic field, the net force on an arbitrary wire depends solely on the vector displacement between endpoints.

• The net magnetic force on any closed current loop in a uniform field is zero.

Force Between Two Parallel Current-Carrying Wires: Force per unit length: F / L = (μ₀ I₁ I₂) / (2π d)

• Parallel currents in the same direction attract.

• Antiparallel currents in opposite directions repel.

Magnetic Dipole And Galvanometer

A planar current loop acts as a magnetic dipole with magnetic dipole moment: μ = n I A

Torque on a current loop in a uniform magnetic field: τ = μ × B. Magnitude: τ = n I A B sin θ

Potential Energy of a Dipole: U = - μ · B

• Stable equilibrium: θ = 0° (μ parallel to B, U = -μB)

• Unstable equilibrium: θ = 180° (μ antiparallel to B, U = +μB)

Moving-Coil Galvanometer: Deflecting torque equals restoring torque of suspension spring: n I A B = k θ

• Current Sensitivity: θ / I = (n A B) / k

• Voltage Sensitivity: θ / V = (n A B) / (k R)

Increasing current sensitivity by raising the turn count (n) does not automatically increase voltage sensitivity, because resistance R increases proportionally with wire length.

Key Revision Tips for Moving Charges And Magnetism Chapter

Follow these key revision tips to master important concepts, avoid common mistakes, and solve numerical problems accurately in the Class 12 Moving Charges and Magnetism chapter.

• Master the Direction Rules First: Always use the right-hand palm rule or right-hand screw rule for cross products (v × B and I dl × r). Remember to flip the final force direction if the particle carries a negative charge (like an electron).

• Keep Kinetic Energy Constant: In purely magnetic fields, speed and kinetic energy never change because force is always perpendicular to velocity. Any increase in kinetic energy requires an electric field component.

• Differentiate Cyclotron Quantities: The orbital period and cyclotron frequency depend strictly on specific charge (q/m) and magnetic field B; they are independent of particle speed and orbit radius.

• Parallel vs. Antiparallel Currents: Remember the opposite convention from electrostatics: like currents attract, unlike currents repel.

• Watch the Limits in Biot–Savart Integrations: When evaluating fields for finite straight wires, carefully trace the angles subtended by both ends to ensure correct signs: B = (μ₀ I / 4π d)(sin θ₁ + sin θ₂).

• Conversion of Galvanometer: To convert a galvanometer to an ammeter, connect a low resistance (shunt) in parallel: S = (I_g × G) / (I - I_g). To convert to a voltmeter, connect a high resistance in series: R = (V / I_g) - G.

Moving Charges and Magnetism ties together the foundations of electromagnetism, establishing how charge motion generates magnetic fields and how external fields exert forces on moving charges and currents. By mastering Biot–Savart's law, Ampere's circuital law, particle kinematics under Lorentz force, and galvanometer mechanics, you secure a strong conceptual baseline for both Class 12 board exams and competitive entrance tests like JEE and NEET. Focus on standard derivations, sign conventions in vector cross-products, and unit conversions to ensure accuracy in numerical problems.
