Units and Measurements Complete Revision Notes: Units, Dimensions, Errors and Significant Figures

Units and Measurements is the foundation chapter of Class 11 Physics. It introduces the language in which every other Physics topic is written—physical quantities, SI units, dimensions, measurement errors and significant figures. A strong hold on this chapter makes formulas, numericals and unit conversions easier to handle in later chapters.

These Units and Measurements revision notes cover the seven fundamental quantities, systems of units, plane and solid angles, large-distance units, dimensional formulae, types of errors and the rules for combining errors. The notes also include important questions, quick revision tips and common mistakes to avoid. Whether you are preparing for school exams or competitive exams, PW’s revision resources can help you strengthen your basics, clear conceptual confusions and attempt Units and Measurements questions with greater confidence.

What are Physical Quantities and How Are They Classified?

A physical quantity is anything that can be measured with a physical instrument, such as length with a scale, temperature with a thermometer or current with an ammeter. Physics deals with measured, experimentally proven results, so every quantity needs a clear way to be measured and reported.

Physical quantities can be classified in two ways: by direction and by dependence. The table shows the first classification.

Why is current a scalar? The main difference between a scalar and a vector is how they add, not whether a direction exists. Two forces of 10 N can give 0 N or 20 N depending on the angle between them. Two currents of 5 A joining in a wire always give 10 A, whatever the angle. So current adds like mass and is treated as a scalar.

What are Fundamental and Derived Quantities?

Fundamental quantities cannot be explained in terms of other physical quantities. Derived quantities are formed from the fundamental ones. Every formula in physics can be built from seven fundamental quantities, as the table shows.

Memory tip: Say "mass, length, time, current, temperature, amount of substance, luminous intensity" a few times and the list stays in your head. Speed, force, work, power, momentum and density are derived quantities.

Why Do We Need Standard Units?

A number alone does not tell us what is measured. The number 5 becomes 5 kg, 5 s or 5 m^2 only when a unit is added. A unit is the standard reference value of a physical quantity, and it must be agreed upon by everyone so that trade and science stay free from confusion.

A good unit has four features:

• Well defined: Its meaning is clear to everyone.

• Invariable: It does not change with time or place.

• Reproducible: Bigger and smaller units can be made from it, such as 1 nanometre = 10^-9 m.

• Convenient: It suits the size of things we measure. The metre suits everyday objects, while the light year suits astronomy and the nanometre suits atoms.

What are the Systems of Units?

Different countries once used different systems, so scientists agreed on one international system. The table lists the common ones.

The SI system is built on the MKS system. It uses the seven base units given earlier and adds two supplementary units, the radian for plane angle and the steradian for solid angle.

What are Plane Angle and Solid Angle?

A plane angle is defined as arc length divided by radius, written as theta = arc length/radius. Both lengths are in metres, so the ratio has no dimensions, but it still has a unit called the radian (rad). Other units are the degree, the minute and the second.

The conversions to remember are:

• 180 degrees = pi radians, so 1 degree = pi/180 radian

• 1 degree = 60 minutes, and 1 minute = 60 seconds (these are angle units, not time)

To convert radians to degrees, multiply by 180/pi. For example, 3pi/4 radian = 135 degrees.

A solid angle is the three-dimensional angle at the tip of a cone. It is defined as omega = area / (radius)^2, and its unit is the steradian (sr). At the centre of a hemisphere, the solid angle is 2pi sr, and at the centre of a full sphere it is 4pi sr. Both angle and solid angle have units but no dimensions.

What Are Dimensions and Dimensional Formulae?

Dimensions are the powers to which the fundamental quantities are raised to represent a physical quantity. For example, velocity = displacement / time, so its dimensional formula is LT^-1. Dimensions show which fundamental quantities a physical quantity depends on. They do not tell us if it is a scalar or a vector, and they do not give the formula itself.

Always write the full dimensional formula with the powers, as marks are cut if a power is missed.

What are the Dimensions of Common Physical Quantities?

Most dimensions can be built from a simple formula in a few seconds. The table lists the formula used and the result, so you can rebuild any entry in the exam.

What Are the Dimensions of Density Terms?

When the word "density" appears, first decide what it is divided by. The table gives the pattern.

Quick rules for the exam:

• Every kind of length has the dimension L. This includes distance, radius, perimeter, radius of gyration, light year, AU and parsec.

• Every kind of velocity is LT^-1 and every kind of acceleration is LT^-2, except angular velocity (T^-1) and angular acceleration (T^-2).

• Thrust, viscous drag, normal reaction, tension and weight are all forces, so they are MLT^-2.

• Anything with the word "gradient" is the quantity divided by length. Pressure gradient is ML^-2T^-2.

• Trigonometric ratios, logarithms and powers (exponents) are always dimensionless. So are angle, solid angle, refractive index and any ratio of two similar quantities.

• Some constants have dimensions (G, h, Boltzmann constant), while numbers like pi and e do not.

How Do You Calculate Absolute, Fractional and Percentage Error?

Take several readings, find their mean, and then find how far each reading is from the mean. The steps are:

1. Mean value: Add all readings and divide by the number of readings.

2. Absolute error: Reading minus mean, for each reading.

3. Mean absolute error: Add all the absolute errors, ignoring the signs, and divide by the number of readings.

4. Fractional (relative) error: Mean absolute error / mean value.

5. Percentage error: Fractional error x 100.

Example: Five readings of a pendulum's time period are 1.8 s, 1.9 s, 2.0 s, 2.1 s and 2.2 s. The mean is 2.0 s. The absolute errors are 0.2, 0.1, 0, 0.1 and 0.2, so the mean absolute error is 0.6 / 5 = 0.12 s. The result is written as 2.0 +- 0.12 s. The fractional error is 0.12 / 2 = 0.06, and the percentage error is 6%.

To cut random error to 1/5 of its value, take 5 times as many readings. Errors of 6 to 7% are generally acceptable in a school experiment.

How Do Errors Combine in Calculations?

When quantities with errors are added, multiplied or raised to powers, the errors also combine. The rules are:

In the power rule, powers are written in front of the fractional errors and every term is added, whether the quantity is in the numerator or denominator. Pure constants such as 1/2 or 4/3 pi carry no error.

For example, if a resistance is R = V / I, then dR/R = dV/V + dI/I. If x = A^2 x B^(1/2) / C^3, then dx/x = 2(dA/A) + 1/2(dB/B) + 3(dC/C).

Warning for large changes: This quick method works only for small percentage changes. If a change is large, find the initial and final values separately. For example, if the velocity increases by 10%, the final velocity is 1.1 v, and the kinetic energy becomes (1.1)^2 = 1.21 times, which is a 21% increase. If the length of a pendulum increases by 44%, the time period becomes the square root of 1.44 = 1.2 times, which is a 20% increase.

Key Tips to Revise Units and Measurements

Short daily practice works better than one long session for this chapter. The tips here help you avoid common mistakes.

• Learn the seven fundamental quantities with their SI units in the right order.

• Build any dimension from a simple formula instead of trying to memorise everything.

• Remember that torque, all energies and work have the same dimensions, and so do pressure, stress and every modulus.

• Do not treat surface tension as a force. It is force per unit length.

• Use the principle of homogeneity by looking at plus, minus and equal signs first.

• Write "dimensionally correct" and not "correct" when the dimensions match.

• For errors, add absolute errors in addition and subtraction, and add fractional errors in multiplication, division and powers.

• Round off only in the last step, and keep the same number of significant figures when converting units.
