SSC JE Electrical Most Important Questions with Answers PDF

SSC JE Electrical Most Important Questions help candidates practise technical questions and revise important Electrical Engineering concepts for the examination. The question set includes multiple-choice questions on electrical machines, circuits, transformers, measuring instruments, power systems, and basic electronics.

Candidates can practise the selected SSC JE Electrical Important Questions with Answers below and check the correct options with explanations. The complete SSC JE Electrical Practice Questions PDF is also available for download, allowing candidates to practise the remaining questions and review their answers.

SSC JE Electrical Important Questions with Answers

The following SSC JE Electrical MCQs cover important technical concepts based on the core SSC JE electrical  syllabus. Check the correct answers and explanations to revise key topics.

Question 1. The phenomenon of crawling in an induction motor is due to which of the following?

(A) Improper design of the machine

(B) Low voltage supply

(C) High load

(D) Harmonics developed in the motor

Answer: (D) Harmonics developed in the motor

Explanation: Crawling is a phenomenon in which an induction motor runs at approximately one-seventh of its synchronous speed. It occurs due to harmonics developed in the motor.

Question 2. What is the magnetising current of a transformer?

(A) The current flowing through the insulation between the primary and secondary windings

(B) The current drawn by the primary winding when the secondary is on open circuit

(C) The current drawn by the secondary winding when a load is connected

(D) The current flowing through the ferromagnetic core

Answer: (B) The current drawn by the primary winding when the secondary is on open circuit

Explanation: Magnetising current is also called excitation current. It flows through the primary winding when the transformer secondary is open and helps produce magnetic flux in the core.

Question 3. What is the advantage of using a DC welding machine over an AC welding machine?

(A) DC welding requires less power than AC welding

(B) DC welding does not require a transformer

(C) DC welding provides better control over arc stability

(D) DC welding eliminates the need for electrode coating

Answer: (C) DC welding provides better control over arc stability

Explanation: DC welding provides better arc stability, which helps produce smoother and more controlled welds.

Question 4. Which statements are correct for measuring current in a circuit using a CRO?

I. A low-resistance standard resistor is connected in series with the circuit.

II. The CRO is connected across the standard resistor to measure the voltage drop.

III. A high-resistance standard resistor is connected in parallel with the circuit.

IV. The CRO is connected in series with the circuit.

(A) Only IV

(B) Only I and IV

(C) Only III and IV

(D) Only I and II

Answer: (D) Only I and II

Explanation: A low-resistance standard resistor is connected in series with the circuit. The CRO measures the voltage drop across this resistor to determine the current.

Note: The questions displayed above are selected from the complete SSC JE Electrical question set. For the remaining questions, correct answers, and detailed solutions, download and refer to the PDF.

SSC JE Electrical Practice Questions PDF Download

Practise the remaining SSC JE Electrical questions to revise important concepts related to electrical machines, circuits, and measuring instruments. Download the complete PDF to access all 50 questions with answers and solutions.

How to Use SSC JE Electrical Questions for Exam Preparation

An organised study plan can help you revise important concepts and prepare more effectively for the SSC JE Electrical examination. SSC JE previous-year questions help you understand question formats and identify topics that need more practice. Follow these steps to improve your SSC JE preparation:

• Learn Core Concepts First: Review basic electrical laws and circuit theorems before solving numerical problems.

• Practice Timed Mock Tests: Solve sets within time limits to improve speed and calculation accuracy.

• Review Mistakes: Identify calculation mistakes and revise weak topics immediately.

• Revise Important Formulas: Revise important electrical formulas and measuring instrument concepts regularly.

For additional preparation, candidates can explore the SSC JE Electrical Engineering syllabus and SSC JE preparation resources.

Practising SSC JE Electrical Most Important Questions, previous year questions, and mock tests can help candidates revise key technical concepts and improve their exam preparation. Download the complete question PDF, review the solutions, and practise regularly to build confidence for the examination.
