Logic Gate: A logic gate is a fundamental building block used to perform logical operations on binary data. It is an electronic circuit that takes one or more binary inputs (0 or 1) and produces a binary output based on predefined logic rules. These gates are the building blocks of more complex digital circuits and are used to perform various logical operations, such as AND, OR, NOT, NAND, NOR, XOR, and XNOR.
AND Gate Truthtable
The AND gate is a fundamental logic gate represented by the Boolean expression Y = A.B. It has two inputs, A and B, and one output, Y. The truth table for the two-input AND gate is as follows:AND Gate Truthtable | ||
Input A | Input B | Output Y |
0 | 0 | 0 |
0 | 1 | 0 |
1 | 0 | 0 |
1 | 1 | 1 |
OR Gate Truthtable
The OR gate is a type of logic gate used in digital circuits. Its Boolean expression is written as Y = A + B, which means Y is equal to A 'OR' B. In simple terms, the OR gate takes two inputs, A and B, and produces one output, Y. Here's the truth table for a two-input OR gate:OR Gate Truthtable | ||
Input A | Input B | Output Y |
0 | 0 | 0 |
0 | 1 | 1 |
1 | 0 | 1 |
1 | 1 | 1 |
NOT Gate Truthtable
The Boolean expression for the NOT gate is written as Y = NOT A, which means Y is equal to "NOT" A. In simpler terms, the NOT gate is like a logical inverter with only one input, A. Its main job is to reverse the logic state of the input signal. If the input A is 1 (true), the output Y becomes 0 (false). Similarly, if the input A is 0 (false), the output Y becomes 1 (true). In other words, the NOT gate switches the value of the input: if you give it a 1, it gives you back a 0, and if you give it a 0, it gives you back a 1. Here's the truth table for the NOT gate:NOT Gate Truthtable | |
Input A | Output Y |
0 | 1 |
1 | 0 |
XOR Gate Truthtable
The XOR gate takes two inputs, A and B, which can have values of 0 (false) or 1 (true). The output of the XOR gate depends on the combination of inputs:XOR Gate Truthtable | ||
Input A | Input B | Output |
0 | 0 | 0 |
0 | 1 | 1 |
1 | 0 | 1 |
1 | 1 | 0 |
NAND Gate Truthtable
The NAND gate takes two inputs, A and B, which can have values of 0 (false) or 1 (true). The output of the NAND gate is the opposite of what you get from an AND gate. It behaves like an AND gate followed by a NOT gate. Here's a quick explanation of the outputs:NAND Gate Truthtable | ||
Input A | Input B | Output |
0 | 0 | 1 |
0 | 1 | 1 |
1 | 0 | 1 |
1 | 1 | 0 |
NOR Gate Truthtable
In this truth table, the NOR gate takes two inputs, A and B, which can have values of 0 (false) or 1 (true). The output of the NOR gate is the opposite of what you get from an OR gate. It behaves like an OR gate followed by a NOT gate (inverter). Here's a quick explanation of the output:NOR Gate Truthtable | ||
Input A | Input B | Output |
0 | 0 | 1 |
0 | 1 | 0 |
1 | 0 | 0 |
1 | 1 | 0 |
XNOR Gate Truthtable
The XNOR gate takes two inputs, A and B, which can have values of 0 (false) or 1 (true). The output of the XNOR gate represents whether the inputs are the same or different. Here's a quick explanation of the outputs:XNOR Gate Truthtable | ||
Input A | Input B | Output |
0 | 0 | 1 |
0 | 1 | 0 |
1 | 0 | 0 |
1 | 1 | 1 |
